Camera

Image Sensor: 1/2.7" Progressive Scan CMOS

Shutter Speed Self-adaptive shutter

Lens 4mm @ F1.6, viewing angle: 82° (Horizontal), 48° (Vertical), 98° (Diagonal)

Lens Mount: M12

Day & Night: IR-cut filter with auto-switching

DNR :3D DNR

WDR: Digital WDR

Compression

Video Compression H.264/H.265

Video Bit Rate Adaptive bit rate.


Max. Resolution: 2304 × 1296

Frame Rate: Self-Adaptive during network transmission

Network

Smart Alarm: Motion Detection, Human Shape Detection, Loud Noise Detection

Wi-Fi Pairing: AP paring

Protocol: EZVIZ Cloud Proprietary Protocol

Interface Protocol: EZVIZ Cloud Proprietary Protocol

Interface

Storage: Supports microSD card (Up to 512 G)

Power: TYPE-C

Wired Network: RJ45 X 1 (10M/100M self-adaptive Ethernet port)

Wi-Fi

Standard IEEE802.11b, 802.11g, 802.11n

Frequency Range: 2.4 GHz ~ 2.4835 GHz

Channel Bandwidth Supports 20MHz

Security WPA/WPA2, WPA-PSK/WPA2-PSK

Transmission Rate 11b: 11Mbps, 11g :54Mbps, 11n :72Mbps

Output Power(EIRP) 19 dBm

Antenna Gain 1.9 dBi

General

Operating Conditions: -10°C to 45°C (14°F to 113 °F ), Humidity 95% or less (non-condensing)

Power Supply: DC 5V/1A

Power Consumption: 5W max

IR Range MAX. 10 meters (33ft)

Dimensions: 88mm x 88.2 mm x 119mm (3.46” x 3.47” x 4.69”)

Packaging Dimensions: 103mm x 103mm x 168mm (4.06” x 4.06” x 6.61”)

Bare Weight: 218g (0.48lb)

In the box

In the box - Camera

- Power Adapter

- Power Cable

- Drill Template

- Mounting Plate

- EZVIZ Screw Kit

- Regulatory Information

- Quick Start Guide
