Printing Method Direct Thermal

Resolution 8 dots/mm(203 DPI)

Interface USB2.0 (Standard)

Optional accessories TF card slot, RTC clock, peel off module, Cutter module

Max Print Speed 152 mm (6")/s

Max Print Width 108mm (4.25”)

Max Print Length 1778mm

Media Type Continuous, gap, black mark, fan-fold and punched hole

Media Width 20 mm ~ 115 mm

Media Thickness 0.06 mm ~ 0.25 mm

Media Length 10 mm ~1778 mm

Paper roll diameter 25.4 ~ 76.2 mm (1" ~ 3")

Paper thickness 0.06 mm ~ 0.25 mm

Label Roll Capacity 127 mm (5”) external diameter

Memory 8MB Flash Memory

8MB SDRAM

Sensor Gap sensor

Printer Head opened sensor

Black mark sensor

Processor 32-bit RISC CPU

Power Supply Input: AC 100-240V; Output: DC 24V/2.5A

Barcode 1D barcode: Code 39, Code 93, Code 128UCC, Code 128, subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8,EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST, GS1 DataBar, Code11

2D barcode: PDF-417, Maxicode, DataMatrix, QR code, Aztec

Emulation TSPL \ EPL \ ZPL \ DPL

Dimension 215 mm x 178 mm x 155 mm

Weight 1.31 kg

Safety Standard FCC, CE, CB, CCC

Environment Operation condition: -10 ~ 50℃ (14 ~ 122 °F) ,10 ~ 90% non-condensing

Storage condition : -40 ~ 60℃ (-40 ~ 140 °F), 10 ~ 90% non-condensing
