Door station/Video parameters

Resolution 1920 × 1080

Stream resolution: 960 × 576

Lens 1/2.7" CMOS

FOV

Horizontal: 66.2°，Vertical: 37.2°

Door station/Audio parameters

Audio input Built-in omnidirectional microphone

Audio output Built-in loudspeaker

Door station/Device interfaces

I/O output 1 relay output

Four-wire 1-ch video input, 1-ch audio input/output, 1-ch power supply, 1-ch grounding

Door station/General

Power supply 12 VDC

Power consumption Max. 5W

Working temperature -10° C to + 55° C (14° F to 131° F)

Working humidity 10% to 90%

Dimensions 128 mm × 42 mm × 24.8 mm

Protective level IP65

Indoor station/Display parameters

Operation method Physical button

Type 7-inch colorful TFT LCD

Resolution 800 × 480

Built-in loudspeaker

Audio quality Noise suppression and echo cancellation

Indoor station/General

Power supply 12 VDC

Power consumption≤5 W

Working temperature -10° C to + 55° C (14° F to 131° F)

Working humidity 10% to 90%

Dimensions (W × H × D)

195.8 mm × 132.8 mm × 18.39 mm (7.7" × 5.2" ×0.7")
