Advanced Motion Detection DVR with 4-Channel HD Video Input and Deep Learning Capabilities

This powerful DVR system combines deep learning motion detection, versatile video input, and high-definition output for robust surveillance performance.

• Intelligent Motion Detection 2.0: Enhanced by deep learning, Motion Detection 2.0 is enabled by default for all analog channels. It classifies humans and vehicles, significantly reducing false alarms triggered by objects like leaves or lights.

• Quick Search by Object or Event: Streamline searches by filtering events based on object or type, improving retrieval efficiency.

Video and Audio Capabilities

• IP Video Input: Supports up to 1 IP channel (expandable to 5 channels) with up to 1080p resolution, compatible with H.265+/H.265/H.264+/H.264 IP cameras.

• Analog Video Input: Provides 4 analog channels with a BNC interface, supporting coaxitron connections.

• Multiple HD Inputs: Compatible with HDTVI, AHD, and HDCVI inputs at 1080p and 720p resolutions.

• HDMI and VGA Output: Output up to 1920 x 1080 resolution for clear display on both HDMI and VGA devices.

• Audio Input and Output: Includes 1 RCA audio input and 4 channels via coaxial cable, along with two-way audio and 1 RCA output for enhanced audio capabilities.

Recording and Compression

• Advanced Video Compression: Supports H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 compression for efficient recording and storage.

• Recording Resolution: Allows recording at 1080p Lite and 720p Lite for higher definition, with other options for SD and CIF resolutions.

• Frame Rate Options: Main stream offers up to 1080p Lite and 720p Lite at 25 fps (PAL) and 30 fps (NTSC), while sub-stream supports 4CIF and CIF at 25 fps (PAL) and 30 fps (NTSC).

• Audio Compression: Utilizes G.711u audio compression for clear audio recording at 64 Kbps.

Networking and Storage

• Network Bandwidth and Protocols: Supports 64 Mbps total bandwidth, with protocols such as TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP™, HTTPS.

• Remote Connections: Manage up to 32 remote connections for flexible access to the DVR.

• Storage and USB Interface: Equipped with 1 SATA interface supporting up to 4 TB and 2 USB 2.0 ports for external storage and file transfers.

General Specifications

• Power Supply and Consumption: Operates on 12 VDC, 1.5 A with a maximum power consumption of 16 W (without HDD).

• Operating Conditions: Suitable for temperatures between -10 °C to 55 °C (14 °F to 131 °F) and humidity levels of 10% to 90%.

• Compact Design: Measures 200 x 200 x 48 mm (7.9 x 7.9 x 1.9 in) and weighs 0.8 kg (1.8 lb.) without the HDD, making it easy to install and handle.
