DS-3E0109P-E/M(B) 8 Port Fast Ethernet Unmanaged POE Switch

Why Choose DS-3E0109P-E/M(B)?

• Intelligent POE Management: When the power supply exceeds the limit, POE ports intelligently manage the power supply, extending the switch's lifetime.
• Up to 300 m Long-Range POE Transmission: The distance between IPCs and the switch can reach up to 300 meters.
• 4/8-Core Adaptive Power Supply with Less Power Loss: The 8-core power supply reduces power loss on cables.
• 6KV Surge Protection for Harsh Environments: Built-in surge protection protects the switch from sudden lightning surges.
• Designed for Video Transmission: VIP port ensures important data transmission during network congestion.

• General Specifications:
• Shell Material: Metal
• Net Weight: 0.35 kg (0.77 lb)
• Gross Weight: 0.89 kg (1.96 lb)
• Dimensions (W × H × D): 170 mm × 27.6 mm × 93.1 mm (6.7'' × 1.1'' × 3.7'')
• Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F)
• Storage Temperature: -40 °C to 85 °C (-40 °F to 185 °F)
• Operating Humidity: 5% to 95% (non-condensing)
• Power Supply: 48 VDC, 1.35 A
• Max Power Consumption: 65 W
• Idle Power Consumption: 5 W
• Installation Mode: Desk-mounted or wall-mounted
• Surge Protection: 6 KV
• Network Specifications:
• Ports:
• 8 × 10/100 Mbps POE ports
• 1 × 10/100 Mbps RJ45 port
• MAC Address Table: 2K
• Switching Capacity: 1.8 Gbps
• Packet Forwarding Rate: 1.34 Mpps
• Internal Cache: 1 Mbit
• POE Power Supply:
• POE Standard:
• IEEE 802.3af
• IEEE 802.3at
• POE Power Pin Assignment:
• 8-core power: 1/2(-), 3/6(+), 4/5(+), 7/8(-)
• POE Ports: Ports 1 to 8
• Max Port Power: 30 W
• POE Power Budget: 60 W
• Long-Range Function:
• Ports: Ports 1 to 8 support up to 300 m.
