6 MP Smart Hybrid Light Fixed Dome Network Camera DS-2CD1163G2-LIU

The DS-2CD1163G2-LIU is a high-performance fixed dome network camera that delivers outstanding image quality with its 6 MP resolution. It supports advanced human and vehicle detection, making it ideal for modern surveillance systems. The camera is equipped with Smart Hybrid Light technology, providing clear imaging in low light conditions with a long range. With H.265+ compression technology, the camera ensures efficient bandwidth usage. It also supports onboard storage (up to 512 GB), and features a built-in microphone for real-time audio security. The camera is IP67-rated for water and dust resistance and IK08-rated for vandal resistance.

Why Choose DS-2CD1163G2-LIU?

• High-quality imaging: 6 MP resolution for clear and detailed footage.
• Human and Vehicle Detection: Advanced detection technology for improved security.
• Smart Hybrid Light: Advanced technology with long-range illumination for better low-light performance.
• Efficient Compression: H.265+ for reduced bandwidth and storage requirements.
• On-board Storage Support: MicroSD card slot supports up to 512 GB (optional).
• Built-in Microphone: Enables real-time audio surveillance.
• Durability: IP67-rated water and dust resistance and IK08-rated vandal resistance.

Key Details:

• Image Sensor: 1/2.4" Progressive Scan CMOS
• Max. Resolution: 3200 × 1800
• Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
• Shutter Time: 1/3 s to 1/100,000 s
• Day & Night: IR cut filter
• Angle Adjustment: Pan: 0° to 355°, Tilt: 0° to 75°, Rotate: 0° to 355°
• Lens:
• Lens Type: Fixed focal lens, 2.8 mm
• Focal Length & FOV:
• 2.8 mm, Horizontal FOV 105°, Vertical FOV 55°, Diagonal FOV 127°
• Lens Mount: M12
• Iris Type: Fixed
• Aperture: F1.6
• DORI:
• 2.8 mm: D: 76 m, O: 30 m, R: 15 m, I: 7 m
• Illuminator:
• Supplement Light Type: IR, White Light
• Supplement Light Range: Up to 30 m
• Smart Supplement Light: Yes
• IR Wavelength: 850 nm
• Video:
• Main Stream:
• 50 Hz: 20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
• 60 Hz: 20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
• Sub-Stream:
• 50 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360)
• 60 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360)
• Video Compression:
• Main Stream: H.265+/H.265/H.264+/H.264
• Sub-Stream: H.265/H.264/MJPEG
• Video Bitrate:
• From 32 Kbps to 16 Mbps
• Audio:
• Audio Type: Mono
• Noise Filtering: Yes
• Audio Sample Rate: 8 kHz/16 kHz
• Audio Compression: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC
• Audio Bitrate: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)
